What Is a DWG Planning Map?

A DWG map is a digital vector drawing file supplied in AutoCAD's native .dwg format (or as an open .dxf exchange file). It consists of points, lines, polylines, arcs, and text layers positioned in real-world metric coordinates.

Unlike a flat PDF or raster image:

  • 1:1 Real-World Scale: All linework is drawn at 1:1 scale in model space (1 unit = 1 metre on the ground).
  • Layered Architecture: Physical features — buildings, road edges, pavements, watercourses, and fences — reside on distinct CAD layers that you can toggle, isolate, or colour-code.
  • Object Snapping: Designers can snap drafting tools directly to the exact vector vertex of an existing wall or boundary feature.
  • Georeferencing: Linework is calibrated to the British National Grid (OSGB36), ensuring coordination with topographical surveys and BIM environments.

DWG vs DXF: Which Should You Use?

  • DWG (.dwg): The standard binary file format for Autodesk products (AutoCAD, Civil 3D, Revit). It preserves complex object styles and keeps file sizes compact.
  • DXF (.dxf): Autodesk's Drawing Exchange Format. It is an open ASCII/binary specification supported by virtually every 2D/3D design package, including SketchUp, Vectorworks, Rhino, and BricsCAD.

PlanningMapsUK provides CAD downloads with both formats supported, ensuring complete compatibility across design offices.


Why Design Professionals Require CAD Mapping

Starting a planning scheme on an official OS MasterMap CAD base streamlines architectural workflows:

  1. Eliminates Manual Tracing: Importing native vectors saves hours of digitising low-resolution PDFs, reducing client costs and eliminating human tracing errors.
  2. Accurate Setback Measurements: Real-world coordinates allow exact metric dimensioning between proposed external walls and site boundaries.
  3. Multi-Disciplinary Coordination: Structural engineers, drainage consultants, and landscape architects can work from the exact same georeferenced base model.
  4. Exporting Validation-Ready PDFs: Once the design is frozen, the architect sets up paper-space viewports (1:1250 for location plans, 1:500 for block plans) and exports submission PDFs with matching site boundaries.

Important distinction: While OS MasterMap provides unmatched national topographic accuracy, it is not a substitute for an on-site measured land survey where millimetre-precise finished floor levels, invert levels, or tree root protection zones must be verified.


Layer Structure in OS MasterMap CAD Files

PlanningMapsUK CAD linework is extracted directly from the licensed Ordnance Survey MasterMap Topography Layer. Features are organised into clearly named layers:

Layer NameFeatures Included
BuildingsExternal building wall footprints, residential dwellings, commercial units, and outbuildings
Roads & CarriagewaysMetalled highway surfaces, kerblines, road markings, and roundabout geometry
Pathways & PavementsPedestrian footpaths, cycle tracks, and paved alleyways
Physical BoundariesMapped boundary walls, fences, and hedge lines recorded during OS topographic surveys
Water FeaturesStreams, rivers, canals, ponds, and drainage ditches
Cartographic TextRoad names, house numbers, bench mark elevations, and topographic annotations

Note on Contours: Standard 2D OS MasterMap does not include elevation contours. If your site has significant slope gradients, you can add OS Terrain 5 contour data as an optional CAD overlay through our topographic map and contours page.


Coordinate Systems and Georeferencing (OSGB36 / EPSG:27700)

Every vector entity in our DWG and DXF downloads is strictly anchored to the British National Grid (OSGB36), designated internationally as EPSG:27700.

Understanding how real-world coordinates operate inside your CAD software prevents common coordination headaches:

1. Model Space Coordinates (Easting and Northing)

When you query any point in model space (using the ID command in AutoCAD), the X coordinate represents Easting (e.g. 530214.50) and the Y coordinate represents Northing (e.g. 179420.30). This native positioning allows you to:

  • Reference GPS site survey points without manual rotation or scaling.
  • Overlay external GIS shapefiles, environmental constraints, or statutory flood zone data directly into the drawing.
  • Coordinate seamlessly with structural engineers using British National Grid survey coordinates.

2. Solving "Geometry Too Far From Origin" in AutoCAD and Revit

Because British National Grid coordinates are hundreds of thousands of units away from the origin (0,0), certain 3D modelling programs (like Revit, SketchUp, and older versions of AutoCAD) can exhibit graphic jitter or clipping plane glitches. Here is how leading architectural practices handle this:

  • In AutoCAD: Keep the MasterMap base file in its native OSGB36 coordinates as an external reference (XREF). Create your working project file with an established local User Coordinate System (UCS), or insert the base at a known survey tie-in point.
  • In Autodesk Revit: Link the DWG file into Revit using "Position: Auto - By Shared Coordinates" or "Auto - Center to Center", then acquire coordinates from the DWG file to align Revit's Survey Point with the British National Grid while keeping the Project Base Point close to the building footprint.

Setting Up Viewports: Model Space (Metres) to Paper Space (Millimetres)

One of the most frequent mistakes junior technicians make when working with OS CAD files is manually scaling the map vectors. Never scale the underlying MasterMap geometry.

The professional CAD workflow operates entirely through Paper Space layout viewports:

  1. Model Space Units: Mapped in metres (1 CAD unit = 1.000 metre on site). All building designs, extensions, and site layouts are drafted at full 1:1 real-world size.
  2. Paper Space Layouts: Configured in millimetres (1 paper unit = 1.0 mm).
  3. Viewport Scale Calculations:
    • For a 1:500 Site Plan / Block Plan on an A3 or A4 layout: Set the viewport custom scale to 1000 / 500 = 2.0 (or enter 1000/500xp in the command line).
    • For a 1:1250 Site Location Plan: Set the viewport custom scale to 1000 / 1250 = 0.8 (or enter 1000/1250xp).
    • For a 1:200 Detailed Infill Plan: Set the viewport custom scale to 1000 / 200 = 5.0 (or enter 1000/200xp).

Once the scale is set, lock the viewport (Display Locked: Yes) so an accidental zoom inside it cannot change the scale. Your title block text, north arrow, and graphic scale bar sit in paper space, so they stay at a constant size whatever you do in model space.

Check the Drawing Units Before You Draft

Most scale problems on CAD-based planning sheets start with a units mismatch, not with the map. Many office templates are set up in millimetres, while the OS base is in metres. If you attach the base as an XREF or insert it as a block into a millimetre drawing, AutoCAD can rescale it automatically by a factor of 1,000 based on each file's INSUNITS setting.

Run two quick checks before drawing anything:

  1. Use DIST across a feature you know. A typical house frontage should read as roughly 5 to 10 units, not 5,000 to 10,000.
  2. Use ID on any point. Eastings and northings should be large National Grid values in the tens or hundreds of thousands, not small numbers near zero.

If you draft building details in millimetres, keep them in a separate file with INSUNITS set correctly in both, and never scale the map by hand.


Layer Management and Plot Styles for Planning Submissions

When preparing planning application drawings from your DWG base, structure your layer hierarchy to ensure case officers can easily interpret your proposals:

  • Retain OS Base Layers as Background Context: Dim or grey out the background Ordnance Survey layers using a grey pen (e.g. Colour 8 or 9 in AutoCAD) with fine lineweights (0.09mm to 0.13mm).
  • Create Dedicated Proposal Layers:
    • PR-WALL-EXT: Proposed external walls (0.35mm to 0.50mm bold lineweight).
    • PR-HATCH: Solid grey or diagonal cross-hatching indicating new floor space.
    • SITE-BOUNDARY-RED: Continuous polyline with a minimum 0.50mm lineweight drawn around the statutory application boundary.
    • SITE-BOUNDARY-BLUE: Continuous polyline with a 0.50mm lineweight denoting adjoining land in client ownership.
  • Clean Polylines: Ensure that your red-line site boundary is drawn as a single, closed 2D polyline (PLINE followed by CLOSE). This lets you read the total application site area directly from the polyline's properties. Because model space is in metres, the area is reported in square metres. Divide by 10,000 for hectares, which is the unit most application forms ask for.

Licensing Terms for Architectural and Commercial Use

Ordnance Survey CAD vector data is commercially licensed intellectual property. When purchasing through PlanningMapsUK:

  • Project-Specific Commercial Licence: Your purchase includes legal rights for you, your client, and your project sub-consultants (structural engineers, landscape designers, planning advocates) to use the CAD data in the preparation of planning, building control, and construction documents for that specific development site.
  • No Redistribution Rights: You cannot extract the vector linework to resell as generic mapping or publish raw DWG data openly on public internet repositories.
  • Crown Copyright Inclusion: When plotting or exporting finished planning drawing sheets to PDF for council review, keep the Ordnance Survey copyright acknowledgement on your sheet margin, along the lines of "© Crown copyright and database rights year Ordnance Survey" followed by the licence number supplied with your data.

What Is a DWG Map? — UK planning guide

What Is a DWG Map?.

Scales and Coverage Areas

CAD linework is drawn at 1:1, so "scale" here means the scale you intend to plot at. That decides how large an extract you need to fill the sheet:

  • 1:200: Detailed site and block plans on tight urban plots. A full A4 sheet covers about 42 m x 59 m of ground before margins.
  • 1:500: The most common block plan scale for domestic extensions, garden buildings, and single-plot developments. A4 covers about 105 m x 148 m.
  • 1:1250: The usual location plan scale in urban and suburban areas. A4 covers about 262 m x 371 m (roughly 9.7 hectares), and A3 about 371 m x 525 m.
  • 1:2500: Location plans for larger or rural sites such as farms and estates. A4 covers about 525 m x 742 m.

These are full-sheet figures. Allow for the title block and borders, and order an extract that comfortably fills the viewport at the smallest scale you plan to plot.


How to Order DWG Planning Maps on PlanningMapsUK

  1. Enter Your Address or Coordinates: Locate your site in the map workspace.
  2. Select the Required Coverage Area: Adjust the selection box to encompass the development site and surrounding roads.
  3. Choose CAD Output: Select DWG (or DXF) as your delivery format.
  4. Add Optional Contours if Required: Check the OS Terrain 5 contours option if elevation data is needed.
  5. Instant Download: Complete checkout to receive your georeferenced CAD files immediately.

Pricing is from £14.95, depending on the area covered.


Frequently Asked Questions

What is a DWG map?

A DWG map is an editable vector drawing file supplied in AutoCAD's native drawing format. For UK planning and architectural work, it provides a georeferenced, layered Ordnance Survey base map for drafting proposals.

What is the difference between DWG and DXF?

DWG is AutoCAD's proprietary binary format, while DXF (Drawing Exchange Format) is an open standard designed to transfer CAD geometry smoothly into software like Vectorworks, SketchUp, and Rhino.

Are PlanningMapsUK CAD maps georeferenced?

Yes. All PlanningMapsUK CAD data is positioned accurately in OSGB36 British National Grid coordinates, allowing seamless alignment with GIS datasets and site surveys.

Do CAD planning maps include terrain contours?

Standard OS MasterMap Topography linework is 2D planar data. PlanningMapsUK offers OS Terrain 5-metre contours as an optional CAD overlay where site levels and slope gradients are required.

Can I open a DWG planning map without AutoCAD?

Yes. You can view DWG files using free tools like Autodesk DWG TrueView, or open DXF files in open-source CAD applications like QCAD and LibreCAD.


Professional CAD Mapping for Your Drawing Set

Whether designing a single home extension or coordinating a multi-unit residential scheme, working from native Ordnance Survey CAD data guarantees geometric precision and eliminates drafting delays.

Download your licensed DWG and DXF planning maps today on PlanningMapsUK for immediate integration into your CAD workspace.
