If you have ever prepared a planning submission in the UK, you will have noticed a strict requirement on the council's validation checklist: all submitted maps must be derived from licensed Ordnance Survey mapping.

Why can't you simply upload a screenshot from your smartphone map or an aerial photograph?

The answer lies in the precision and legal status of Ordnance Survey MasterMap®. OS MasterMap is Great Britain's definitive geospatial database, holding hundreds of millions of individual topographic features. Every wall, kerb, and building footprint is surveyed to published national standards.

Here is why local planning authorities mandate OS MasterMap, how licensing works, and why compliant mapping protects your application from costly delays.

If you are ready to order the mapping, start with OS planning maps. If your architect requires editable CAD vector files, view our OS CAD planning maps.


Why do councils insist on Ordnance Survey Licensed Mapping?

Why do councils insist on Ordnance Survey Licensed Mapping?

What Is OS MasterMap?

OS MasterMap is not a static picture. It is a structured topographic database.

In traditional paper mapping, a line is simply a printed stroke of ink. In MasterMap, every single real-world object is a distinct vector polygon or line assigned a unique reference called a TOID (Topographic Identifier), written as osgb followed by up to 16 digits.

The database categorizes each physical feature into functional layers:

  • Buildings: Precise external wall footprints.
  • Roads and Tracks: Metalled surfaces, kerblines, and highway verges.
  • Structures: Overhead walkways, pylons, and footbridges.
  • Land Parcels: Natural surfaces, gardens, fields, and watercourses.

Unmatched Topographic Precision

In urban and suburban areas, MasterMap is maintained to 1:1250 scale standards, capturing details as specific as bay windows, porch steps, and boundary walls. In rural landscapes, it maintains 1:2500 precision across fields, tracks, and woodlands. Mountain and moorland areas are mapped at 1:10 000.

Because council planning officers, highway engineers, and utility providers all calibrate their GIS platforms to MasterMap, a red-line boundary drawn on this base snaps precisely into the council's digital planning register.


Technical Survey Specifications: How MasterMap Achieves Accuracy

Many applicants assume digital mapping is generated purely from satellite photography. In reality, Ordnance Survey MasterMap Topography Layer is maintained through an intensive, multi-layered surveying regime:

1. Absolute Positional Accuracy Standards

Ordnance Survey operates under strict national accuracy specifications measured against the National Grid:

  • Urban Areas (1:1250 Data): Absolute positional accuracy of about 0.5 metres RMSE (Root Mean Square Error). Building footprints and front boundary features are typically positioned to within about half a metre of their true National Grid coordinates.
  • Rural Areas (1:2500 Data): About 1.1 metres RMSE.
  • Mountain and Moorland (1:10 000 Data): About 4.1 metres RMSE.

To achieve this, OS combines aerial photography from survey flights with ground surveyors using satellite positioning (GNSS) tied to its OS Net network of reference stations.

2. Continuous Cyclic Revision Policy

Ordnance Survey keeps the data current through two kinds of revision:

  • Continuous Revision: Major commercial developments, new road networks, bypasses, and large residential housing estates are the priority. OS aims to capture this kind of major change within about six months.
  • Cyclic Revision: Slower and smaller changes are picked up periodically, typically from aerial photography. This is why a domestic extension, a demolished outbuilding or a new fence can take longer to appear.

The OS National Geographic Database (OS NGD) Evolution

In recent years, Ordnance Survey has evolved MasterMap into the OS National Geographic Database (OS NGD). This evolution enhances how spatial data is organized and delivered to modern planning software:

  • Rich Feature Attribution: Traditional CAD maps contained simple lines representing walls. In modern MasterMap and OS NGD extracts, polygons carry detailed descriptive attributes, such as whether a building footprint is a primary residential dwelling, an unheated outbuilding, a commercial warehouse, or a temporary agricultural structure.
  • Building Parts and Heights: The latest datasets incorporate Building Part Data and building height attributes. Standard planning submissions only need 2D plans, but height data can help architects with early daylight and overlooking studies.

How Local Planning Authorities Use MasterMap in Enterprise GIS

When your application is submitted via the Planning Portal, council teams do not simply view the PDF in isolation. The site boundary is plotted in the council's GIS and planning back-office systems.

Inside the council GIS, the site is checked against constraint layers such as:

  • Conservation Area Polygons: Checking whether your red-line polygon intersects designated heritage conservation areas.
  • Article 4 Direction Envelopes: Identifying whether local permitted development rights (e.g. for front porches, boundary walls, or chimney removals) have been revoked across the street.
  • Tree Preservation Orders (TPOs): Cross-referencing registered protected tree coordinates against your proposed construction boundary.
  • Ancient Woodland & SSSI Buffers: Measuring the distance between your proposed building works and protected nature conservation sites.

Because council mapping is built on Ordnance Survey data and National Grid coordinates, a plan drawn on the same base lines up with those layers. A plan from another source is harder to plot and more likely to be queried.


Why Consumer Maps Cannot Be Used for Planning

Applicants occasionally wonder whether a clear screenshot from Google Maps, Apple Maps, or Bing could serve the same purpose. Local councils reject them immediately for three reasons:

1. Inadmissible Projection and Scaling

Consumer web mapping uses the Web Mercator projection (EPSG:3857). Mercator is designed for global panning and navigation, but it exaggerates ground distances more and more at higher latitudes, including across Britain. A distance measured on a Google screenshot does not represent an accurate metric measurement.

In contrast, OS MasterMap is mapped strictly to the British National Grid (OSGB36) — a conformal national coordinate system where 10 metres on the plan corresponds to exactly 10 metres on the ground.

Local planning authorities are public bodies bound by strict copyright legislation. When you submit a planning application, the council must publish your plans onto the public planning register for statutory consultation.

Publishing unlicensed third-party imagery breaches commercial copyright. Valid OS planning maps carry an official Crown copyright statement and an authorised partner licence code (for example: © Crown copyright and database rights 2026 OS AC0000871051). This licence gives the council the legal right to host, publish, and inspect the document.

3. Currency of Physical Data

Satellite photographs can be several years out of date, particularly in semi-rural locations. Ordnance Survey maintains continuous revision cycles, deploying aerial survey flights and ground surveyors to capture new developments, road extensions, and demolitions rapidly.


What is OS MasterMap? — UK planning guide

What is OS MasterMap?.

OS MasterMap vs OS OpenData: Why Resolution Matters

Ordnance Survey provides several free mapping products under its OS OpenData initiative (such as OS OpenMap Local and OS Open Zoomstack).

While OS OpenData is useful for regional environmental studies or high-level neighborhood plans, it is deliberately generalized:

  • Building footprints are simplified or grouped into blocks.
  • Individual property fences and garden boundaries are omitted.
  • Kerblines and narrow access drives are smoothed out.

When a planning officer evaluates an extension proposal, small distances matter. They must verify boundary clearances, neighbour separation distances, and driveway visibility splays. OS OpenData lacks this fine boundary detail. Only OS MasterMap Topography Layer provides the property-level detail councils expect.


MasterMap Export Formats

Because OS MasterMap is pure vector data, it can be exported to suit different project stages:

  1. PDF (Standard Submission Format): A locked, calibrated vector drawing with a metric scale bar, north arrow, and copyright block. This is the document uploaded to the Planning Portal.
  2. DWG / DXF (Architectural CAD): Clean vector linework on separated layers (buildings, roads, boundaries). Architects import this directly into AutoCAD, Revit, or Vectorworks to design proposals without manual tracing.
  3. GeoPackage / SHP / GML (Geographic Information Systems): Georeferenced spatial data used by planning consultants and environmental surveyors for flood modelling and site analysis.

What If the Map Does Not Show a Recent Building?

Even a current MasterMap extract can lag behind the ground. A neighbour's new garage, or your own extension finished last year, may not have been surveyed yet. Small domestic changes generally take longer to appear than new estates and roads.

This does not make the map unusable for planning. The location plan exists to identify the land, and the red line follows the site, not the buildings on it. What matters is that the extract comes from current OS data, not a copy saved from an application several years ago.

Where a missing building affects the proposal, deal with it on the detailed drawings:

  • Show the true existing footprint on your block plan and existing site plan.
  • Ask your designer to mark any unsurveyed neighbouring building that sits close to the works.
  • Mention the difference briefly in your covering letter or statement so the officer is not surprised on the site visit.

A vital distinction to understand when reviewing OS mapping is the difference between a physical boundary and a legal boundary:

  • OS MasterMap records physical features: It shows where walls, hedges, kerbs, and fences exist on the ground at the time of survey.
  • HM Land Registry records legal ownership: It defines legal title boundaries, which are almost always registered as "general boundaries" under Section 60 of the Land Registration Act 2002.

If an existing garden fence was erected 20 centimetres inside the true boundary line, MasterMap will document where the fence currently stands, not where the title deeds might indicate ownership. If you are involved in a boundary dispute, consult your deeds and a chartered land surveyor; an OS map alone does not determine legal title.


Frequently Asked Questions

Is OS MasterMap free to use?

No. While Ordnance Survey publishes generalized open-source data (such as OS OpenData), the high-detail MasterMap Topography Layer is a commercial geospatial product that requires licensed purchase.

Why is a licence number required on my planning map?

UK local planning authorities are legally bound to uphold Crown copyright. A valid OS licence number and copyright notice prove that data royalties have been paid and that the council can legally publish the map on their public register.

No. OS MasterMap documents physical features on the ground (such as fence lines, hedges, kerbs, and wall faces). Legal ownership is documented separately on Land Registry title deeds and title plans.

Can I use the same OS map for a second planning application?

A standard planning map licence covers a specific development proposal at a given address. If you submit a new application years later or alter the site boundary materially, you should obtain a current, updated map.

What is a TOID in Ordnance Survey mapping?

A TOID (Topographic Identifier) is a unique reference, written as osgb followed by up to 16 digits, assigned to every individual geographical feature in Great Britain within OS MasterMap, from a building outline to a stretch of road.


Summary

Submitting an application on unlicensed mapping is the quickest way to guarantee a validation rejection letter.

By generating your plans from official Ordnance Survey MasterMap data, you ensure that:

  • Your application passes initial council validation checks.
  • Your architect and builder work from the same accurately surveyed base as the council.
  • Your submission fully respects national Crown copyright regulations.
