The email from the council arrived before the design was even looked at. The local planning authority had not refused the proposed rear extension—they had marked the application invalid at validation. The uploaded map failed to identify the property in its wider neighbourhood, the boundary on the site plan did not match the location plan, and the driveway had been cropped out before reaching the adopted highway.

This scenario plays out daily across UK planning departments. Applicants search for maps for planning permission, purchase the first file that sounds plausible, and assume a single map satisfies the entire application. In reality, local councils require a complementary set of scaled documents that answer distinct statutory questions: where the property sits, what curtilage is included, and how the proposed development interacts with its boundaries.

This guide explains the map requirements and the order in which to prepare your plans. Choose a site location plan for the wider setting, or create a detailed site plan for the closer view of your plot. The block-plan option starts at 1:500. Compare the options on our OS planning maps page, and check which separate proposed drawings your application needs.

To confirm your required scales before purchasing, use our interactive Which planning map do I need? tool or check our planning map scale chooser.


Need maps for planning permission?

Need maps for planning permission?

Which Maps Are Mandatory for UK Planning Permission?

Under national requirements and guidance in England (Wales and Scotland have similar rules of their own):

  1. A Site Location Plan (1:1250 or 1:2500): Mandatory for every planning application. It establishes the geographic position of the site relative to surrounding roads and settlements.
  2. A Block Plan / Site Plan (1:500 or 1:200): Expected for almost all applications involving physical construction, extensions, outbuildings, or highway alterations. It details how the proposal sits within the property curtilage.
  3. Vector CAD Data (DWG / DXF): Required when an architect, surveyor, or structural engineer is modelling the design in software like AutoCAD, Revit, or Vectorworks.

Applicants frequently become confused because phrases like "site plan", "location plan", and "block plan" are often used interchangeably in casual conversation. In planning practice, the location plan is always a separate document. "Block plan" and "site plan" usually mean the same closer-scale drawing, and councils use either name.


Planning Maps Summary Table

Document NameStandard ScalePrimary Statutory RoleTypical UserWhen to Buy
Site Location Plan1:1250 (urban) / 1:2500 (rural)Establishes site context within the street networkEvery applicantWhenever the council checklist requests a "Location Plan"
Block Plan / Site Plan1:500 or 1:200Shows detailed clearances, footprints, and boundariesApplicants with building workWhenever building, extending, or altering site access
OS CAD Vector MapLayered DWG/DXFProvides raw OS linework for architectural draftingArchitects, engineers, surveyorsWhen your designer requests editable CAD base mapping
Planning Map PackBundled 1:1250 + 1:500Bundles location and block plans in a single orderHomeowners & buildersThe recommended standard for all residential projects

Why Councils Require Two Complementary Maps

Planning officers must evaluate your project against two distinct legal criteria:

1. Where Is the Application Land?

This is answered by the Site Location Plan. It identifies the property boundaries on official Ordnance Survey mapping, highlights the site in red, indicates adjoining ownership in blue, and links the parcel to the council's central GIS layers.

2. How Does the Proposal Affect the Immediate Surroundings?

This is answered by the Block Plan. It zooms in to illustrate building footprints, distances to neighbouring fences, tree preservation locations, parking spaces, and sightlines to the highway.

A location plan cannot provide the close-up measurement detail needed to evaluate an extension's impact on a neighbour's daylight. Conversely, a block plan is too zoomed in to locate the property within the local road network. You need both.


The Order to Prepare Your Plans

Working in this order avoids redrawing a boundary halfway through:

  1. Read your council's local validation list. It confirms which plans and scales that authority expects for your type of application.
  2. Settle the red line first. Decide what land the development needs, including the access to the public highway, and what other land you own nearby for the blue line.
  3. Produce the location plan. The red line on this sheet decides which ownership certificate you sign, so it comes before anything else.
  4. Produce the block plan from the same base map and boundary. Then add the proposal, dimensions to boundaries, parking and trees.
  5. Give your designer the same base. Proposed site plans and elevations drawn over a different map are a common source of mismatched boundaries.
  6. Compare every sheet before you upload. The red line should be the same shape on each one.

Essential Elements for a Valid Location Plan

To pass council validation without delays, your site location plan should include the following. Only the plan itself, its scale and the direction of north come from statute. The rest reflects national guidance and typical local validation lists:

  • Official licensed Ordnance Survey MasterMap base linework with valid Crown copyright.
  • A continuous red-line boundary outlining the entire property and access route to the public highway.
  • A blue-line boundary outlining any other nearby land owned or controlled by the applicant.
  • A clearly marked True North arrow.
  • A calibrated metric graphic scale bar.
  • Standard statutory scale (typically 1:1250 for residential or 1:2500 for rural holdings).
  • At least two named surrounding roads where possible, so the site can be found quickly.

Essential Elements for a Valid Block Plan

A compliant block plan (often drawn at 1:500) should show, where relevant:

  • The footprint of the proposed extension or building clearly distinguished from existing structures.
  • Accurate metric dimensions from the new walls to property boundaries.
  • Positions of existing trees, hedges, and outbuildings.
  • Vehicle parking bays and access arrangements.
  • Public rights of way or footpaths crossing or adjoining the site.

The Lifecycle of Planning Maps: From Initial Concept to Planning Appeal

Planning maps are not a one-off hurdle; they evolve across the lifecycle of a development project:

Stage 1: Feasibility and Architectural Drafting

Before submitting anything to the council, your design team needs an accurate base map. Procuring an official OS MasterMap CAD export (DWG) at this stage eliminates manual measuring errors. Architects import the vector lines directly into 3D modelling software to test sunlight paths, massing, and initial client sketches.

Stage 2: Pre-Application Consultations

If your scheme is ambitious or situated in a sensitive rural setting, submitting a formal pre-application enquiry to the council is standard practice. Most councils ask for a 1:1250 location plan with the enquiry so case officers can run desktop constraint searches and find the site.

Stage 3: Formal Planning Submission (The Portal Package)

Once designs are finalised, the statutory planning map pack (1:1250 location plan + 1:500 block plan) is locked to PDF and uploaded alongside the Planning Portal forms, architectural elevations, and design statements.

Stage 4: Discharge of Planning Conditions

When planning permission is granted, it routinely comes with "pre-commencement conditions". For example, Condition 3 might state: "Prior to commencement, a detailed hard and soft landscaping scheme shall be submitted to and approved in writing by the LPA." To discharge this condition, landscape designers take the approved 1:500 block plan and annotate tree species, lawn turfing, permeable patio materials, and external lighting positions.

Stage 5: Planning Appeals (The Wheatcroft Principle)

If your application is refused by the council and you appeal to the Planning Inspectorate (PINS) under Section 78 of the Town and Country Planning Act 1990:

  • The Planning Inspector will only assess the exact red-line boundary and plans considered by the local planning authority.
  • Under the landmark legal precedent Bernard Wheatcroft Ltd v Secretary of State for the Environment 1982, an appellant cannot fundamentally alter the red line or introduce substantially revised site plans during an appeal if doing so would deprive interested neighbours of consultation.

Many applicants fail to realise that the geometry of their red-line boundary legally dictates which Ownership Certificate must be signed under Section 65 of the Town and Country Planning Act 1990:

  • Certificate A (Sole Ownership): You can only sign Certificate A if you own 100% of the freehold or leasehold (with at least 7 years remaining) of every square inch of land inside the red line, including the entire driveway connecting to the council-maintained public road.
  • Certificate B (Shared Ownership or Third-Party Land): If your red line crosses a private shared road, communal parking court, or any land owned by a neighbour or freeholder, you must sign Certificate B. Certificate B confirms that you have served formal notice on everyone who was an owner of any part of that land (a freeholder, or a leaseholder with at least 7 years left) in the 21 days before the application date. It is not a 21-day waiting period before you can submit.
  • Certificate C & D (Unknown Owners): If the owner of a private access lane cannot be identified after reasonable search (such as checking Land Registry records), you must publish a formal public notice in a local circulating newspaper.
  • Criminal Liability: Under Section 65(6) of the Act, knowingly or recklessly completing a false ownership certificate is a criminal offence punishable by a fine, and a permission granted on the basis of a false certificate is open to legal challenge.

Fast comparison: which map does what? — UK planning guide

Fast comparison: which map does what?

Choosing Between PDF and CAD Formats

  • Choose PDF: If you are managing your own submission on the Planning Portal and your architectural drawings are already complete. Our PDFs are delivered at exact metric scales ready for immediate upload.
  • Choose CAD (DWG / DXF): If you are working with an architectural designer or surveyor who needs to import licensed OS MasterMap coordinates directly into CAD software. This saves your design team hours of manual tracing and prevents geometric inaccuracies.

Frequently Asked Questions

Which maps are required for a UK planning application?

Most applications involving building work require two maps—a 1:1250 site location plan showing the property within the wider street context, and a 1:500 block plan detailing proposed building footprints and boundary setbacks. Rural sites may require 1:2500 for the location plan.

Do I always need both a location plan and a block plan?

For almost all building projects, yes, including extensions, outbuildings, dropped kerbs, and new dwellings. Applications with no external works (such as a simple change of use) may be accepted with just a location plan. Check your council's local validation list.

What is the difference between a planning map and an architectural drawing?

Planning maps are scaled plans based on Ordnance Survey data showing the application site and its street context. Architectural drawings illustrate design and structural specifics, including internal floor plans, exterior elevations, and cross-sections.

Can I submit Land Registry title plans or Google Maps screenshots?

Not as they stand. A Land Registry title plan shows the registered title, not the application site, and Google Maps screenshots are not licensed for planning use and have no reliable metric scale. Councils routinely return both as invalid.

When do I need vector CAD files instead of PDF planning maps?

You only need CAD formats (DWG or DXF) if an architect, technologist, or structural engineer is drafting proposed layouts inside CAD software. If you are uploading directly to the Planning Portal yourself, high-resolution PDFs are sufficient.

What is the fastest way to obtain council-approved planning maps?

Use a licensed online planning map generator to create your 1:1250 location plan and 1:500 block plan in a single session. This ensures boundary coordinates, OS MasterMap editions, and metric scales match seamlessly.


Summary

To ensure your planning application passes validation without delay:

  • Order a 1:1250 site location plan to establish street context and highway access.
  • Include a 1:500 block plan showing building footprints and boundary clearances.
  • Ensure your red-line boundary is identical across all submitted documents.
  • Provide DWG CAD mapping if your architect is drafting technical drawings.
